Bag Filtration System

Get a Price/Quote

MOQ : 1 Unit

Bag Filtration System Specification

Orientation
Vertical/Horizontal

Efficiency
>99%

Scrubber Type
Dry

Sensor Type
Dust Sensor (Optional)

Instruments Type
Filtration System

Air Flow
502000 m/hr

Measurement
Particulate Concentration

Automation Grade
Semi-Automatic/Automatic

Power Source
Electric

Usage & Applications
Industrial dust & particulate filtration for air pollution control

Temperature
Up to 60C

Product Type
Bag Filtration System

Material
Mild Steel (Powder Coated)

Cooling System
Air Cooled

Noise Level
<75 dB

Processing Time
Continuous

Capacity
502000 m/hr

Voltage
220240 V AC

Weight
Approx. 200800 kg (varies with model)

Dimension (L*W*H)
Customizable

Surface
Powder Coated

Cleaning Mechanism
Pulse Jet (Compressed Air)

Maximum Operating Pressure
0.5 bar

Color
Blue / Customizable

Corrosion Resistance
Yes

Inlet/Outlet Connection
Flanged

Frame Structure
Heavy-duty Steel

Installation Location
Indoor & Outdoor

Dust Discharge
Manual/Automatic Valve

Number of Bags
124 (depending on model)

Bag Removal Method
Top or Bottom Removal

Filter Bag Material
Polyester, Polypropylene

Bag Filtration System Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
2 Units Per Month

Delivery Time
2 Days

Sample Available
No

Main Domestic Market
Madhya Pradesh

Certifications
IBR Registered

About Bag Filtration System

Since our inception in the market, our enterprise has become one of the well known manufacturers and suppliers ofBag Filtration System. Offered in various technical system, this system is used to reduce boiler flue gas exhaust pollutants to up to the norms oflocal pollution control board. . The offered system is manufactured under the strict guidance of our deft professionals using premium quality components and latest techniques. In addition to this, we are providing this Bag Filtration System to the customers in various technical specifications at the most reasonable prices.

Features:

Energy efficient
Longer service life
Superior performance
Easy changeover of filters

Reliable Particulate Filtration for Industry

Our bag filtration system is designed to capture fine dust and particulates, enhancing workplace air quality and supporting regulatory compliance. Its pulse jet cleaning mechanism maintains efficient operations with minimal interruption, making it suitable for round-the-clock industrial use.

Customizable for Diverse Applications

With a range of options for bag materials, number of bags, and system configurations, this equipment can be tailored for specific site needs. Its modular design supports both top and bottom bag removal, customizable frame sizes, and user-defined colors.

Built for Durability and Safety

Constructed from powder-coated mild steel, this system is built for long-term use and corrosion resistance. It is engineered to operate in both indoor and outdoor settings, offering flexibility and reliable performance in harsh industrial environments.

FAQs of Bag Filtration System:

Q: How does the pulse jet cleaning mechanism work in this bag filtration system?

A: The pulse jet cleaning mechanism uses bursts of compressed air to dislodge dust and particulates from the filter bags. This ensures that filtration remains efficient over long operational cycles, allowing for continuous system operation with minimal manual intervention.

Q: What are the installation options for this filtration system?

A: The system can be installed both indoors and outdoors, thanks to its corrosion-resistant, powder-coated mild steel construction. Customizable dimensions and orientation options (vertical or horizontal) make it adaptable to various industrial spaces.

Q: When should I choose top or bottom bag removal for my application?

A: Top bag removal is recommended when accessibility from above is convenient or when installed indoors with limited floor clearance. Bottom removal, conversely, is ideal for installations where lower access is more practical, such as outdoor or pit-mounted setups.

Q: Where can this filtration system be used?

A: This system is suitable for a wide range of industrial applications, including dust and particulate collection in manufacturing, processing, and other air-polluting environments. It supports both dry scrubber operations and general air filtration requirements.

Q: What are the maintenance requirements and benefits of using this system?

A: Routine maintenance includes periodic bag inspection and dust discharge management. The pulse jet cleaning system reduces manual cleaning needs, improving overall equipment lifespan, workplace safety, and air quality compliance.

Q: How customizable is the bag filtration system for different processes?

A: The system allows customization in number of filter bags, bag material (polyester or polypropylene), frame size, color, and automation grade (semi-automatic or automatic). Inlet/outlet sizes and operational flow rates can also be tailored to specific site requirements.

Q: What benefits does the systems efficiency provide to industrial users?

A: Achieving over 99% filtration efficiency, this system minimizes particulate emissions, ensures compliance with environmental regulations, and promotes healthier, cleaner workspaces, all while maintaining low noise output and reliable round-the-clock performance.
